German Style F-Clamps(DIN 5117 Standard Compliant)
Max Clamping Force: 1700 N – 8000
NThroat Depth Options: 50 mm – 175 mm
Performance: Zero bending under rated load
Technical Specifications
| Model No. | Clamping Capacity | Throat Depth | Max Clamping Force | Bar Size | Spindle Diameter | Weight |
| DY-DF-100 | 100 mm (4″) | 50 mm (2″) | 1700 N | 16×40 mm | M10 | 0.8 kg |
| DY-DF-150 | 150 mm (6″) | 60 mm (2.4″) | 2200 N | 16×40 mm | M10 | 1.0 kg |
| DY-DF-200 | 200 mm (8″) | 70 mm (2.8″) | 2800 N | 18×45 mm | M12 | 1.5 kg |
| DY-DF-300 | 300 mm (12″) | 80 mm (3.1″) | 3500 N | 20×50 mm | M14 | 2.2 kg |
| DY-DF-400 | 400 mm (16″) | 95 mm (3.7″) | 4200 N | 22×55 mm | M16 | 3.1 kg |
| DY-DF-500 | 500 mm (20″) | 110 mm (4.3″) | 5000 N | 25×60 mm | M18 | 4.3 kg |
| DY-DF-600 | 600 mm (24″) | 125 mm (4.9″) | 5800 N | 28×65 mm | M20 | 5.7 kg |
| DY-DF-800 | 800 mm (32″) | 140 mm (5.5″) | 6800 N | 30×70 mm | M22 | 8.2 kg |
| DY-DF-1000 | 1000 mm (40″) | 160 mm (6.3″) | 7500 N | 32×75 mm | M24 | 11.0 kg |
| DY-DF-1500 | 1500 mm (60″) | 175 mm (6.9″) | 8000 N | 35×80 mm | M27 | 16.5 kg |
* Custom sizes available upon request
